Overview
The Bitchat integration enables MeshCore devices to communicate with the Bitchat Android app through a bridge layer that translates between Bitchat protocol and MeshCore mesh networking. This is an additive feature that preserves all existing MeshCore functionality while adding Bitchat compatibility.
Key Principles
Additive, Not Substitutive: Bitchat support is added alongside MeshCore, not replacing itNo Infrastructure Changes: Repeaters and room servers require no modificationsEncapsulation Strategy: Bitchat messages are encapsulated in standard MeshCore packetsBackward Compatible: Existing MeshCore nodes continue to work normally
Architecture
┌──────────────────────────────────────────────────────────────────────────┐
│ MeshCore Device │
├──────────────────────────────────────────────────────────────────────────┤
│ │
│ ┌─────────────────────────────┐ ┌────────────────────────────────┐ │
│ │ WITH DISPLAY (Menu) │ │ BUTTON-ONLY (T1000-E) │ │
│ │ ┌─────────────────────┐ │ │ ┌────────────────────────┐ │ │
│ │ │ BITCHAT Page │ │ │ │ 5x Button Press │ │ │
│ │ │ ┌─────┐ ┌─────┐ │ │ │ │ (Quintuple) │ │ │
│ │ │ │ M │ │ B │ │ │ │ │ ┌──────────────────┐ │ │ │
│ │ │ │Mesh │ │BitC │ │ │ │ │ │ LED: 3 blinks │ │ │ │
│ │ │ └──┬──┘ └──┬──┘ │ │ │ │ │ Buzzer: tone │ │ │ │
│ │ │ └────┬───┘ │ │ │ │ └────────┬─────────┘ │ │ │
│ │ └──────────┼──────────┘ │ │ └───────────┼────────────┘ │ │
│ └──────────────┼──────────────┘ └───────────────┼────────────────┘ │
│ │ │ │
│ └───────────────────┬───────────────┘ │
│ ▼ │
│ ┌────────────────────────────────────────────────────────────────────┐ │
│ │ SerialBLEInterface │ │
│ │ • MeshCore UART Service (6E400001-B5A3-F393-E0A9-E50E24DCCA9E) │ │
│ │ • Bitchat Service (F47B5E2D-4A9E-4C5A-9B3F-8E1D2C3A4B5C) │ │
│ │ • Only ONE service advertised at a time │ │
│ │ • Auto-disconnects clients on mode switch │ │
│ │ • PIN auth (MeshCore) / Open access (Bitchat) │ │
│ └────────────────────────────────┬───────────────────────────────────┘ │
│ │ │
│ ┌───────────▼────────────┐ │
│ │ BitchatBridge │ │
│ │ • Encapsulate │──► MeshCore GRP/TXT │
│ │ • Decapsulate │◄── BC magic header │
│ │ • Loop prevention │ │
│ └───────────┬────────────┘ │
│ │ │
│ ┌───────────▼────────────┐ │
│ │ MyMesh │ │
│ │ (MeshCore) │ │
│ └───────────┬────────────┘ │
│ │ │
│ ┌───────────▼────────────┐ │
│ │ LoRa Radio │ │
│ │ (SX1262/etc) │ │
│ └────────────────────────┘ │
└──────────────────────────────────────────────────────────────────────────┘
Platform Support
With Display (Menu-Based)
Navigate to the BITCHAT page and press ENTER to toggle between modes. Display shows large M (MeshCore) or B (Bitchat).
Button-Only (T1000-E)
Press the user button 5 times rapidly (within ~3 seconds) to toggle modes. See Button-Based Mode Switching for details.
Quick Start
Enable Bitchat (For Developers)
Add to your platformio.ini:
build_flags =
-D ENABLE_BITCHAT=1
-D BLE_MODE_SWITCHING=1
Check Device Compatibility
Bitchat requires either a display with buttons OR button-only with LED feedback for mode switching.
📋 See Complete Device List — Find your specific device
Quick Start
Enable Bitchat Support
# Build with Bitchat support
export ENABLE_BITCHAT=1
pio run -e WioTrackerL1_companion_radio_ble
Runtime Control
Bitchat mode is controlled on-device via the UI or button presses:
With Display:
Navigate to BITCHAT page using LEFT/RIGHT buttonsPress ENTER to toggle between MeshCore and Bitchat modesDisplay shows large M (MeshCore) or B (Bitchat)
Button-Only (T1000-E):
Press user button 5 times rapidly (within ~3 seconds)LED blinks 3 times (fast=Bitchat 150ms, slow=MeshCore 500ms)Buzzer plays acknowledgment tone (if available)
Note: The device always boots in MeshCore mode. Mode is not persisted across reboots.
Message Flow
Bitchat → MeshCore
Bitchat app sends MESSAGE via BLE to #mesh channelBitchatBLEService receives and parses messageBitchatBridge formats for MeshCore with 📱 prefixMessage sent as PAYLOAD_TYPE_GRP_TXT via mesh on #mesh channel
MeshCore → Bitchat
MeshCore receives group message on #mesh channelBitchatBridge verifies channel secret matches SHA256(“#mesh”)BitchatBridge detects non-Bitchat origin (no 📱 prefix)Message formatted as Bitchat MESSAGE with TLV payloadSent to Bitchat app via BLE notification for #mesh channel
#mesh Channel
The #mesh hashtag channel is the primary interoperability channel between Bitchat and MeshCore.
Channel Key Derivation
#mesh secret = first_16_bytes(SHA256(“#mesh”))
= 0x5B664CDE0B08B220612113DB980650F3
The channel secret is the first 16 bytes of the SHA256 hash of the UTF-8 encoded channel name string (including the # prefix).
Both Bitchat Android app and MeshCore firmware derive the same channel secret using this mechanism, enabling seamless group messaging.
Firmware Implementation
Secret Computation: BitchatBridge::computeMeshSecret() derives the secret at initializationChannel Verification: BitchatBridge::isMeshChannel() verifies messages belong to #meshChannel Initialization: MyMesh::addHashtagChannel(“mesh”) creates the channel on startup
See Protocol Specification for technical details.
Known Limitations
Menu-Based BLE Mode Switching
Due to BLE advertising size constraints, both nRF52 and ESP32 platforms use menu-based switching rather than simultaneous services:
Navigation:
Use LEFT/RIGHT keys to navigate to the BITCHAT pageDisplay shows:“M” with “MeshCore” text → MeshCore mode active“B” with “Bitchat” text → Bitchat mode activePress ENTER to toggle between modes
Platform-Specific Implementation:
nRF52: Switches advertisement data between Nordic UART and Bitchat service UUIDsESP32: Uses setBitChatMode() to dynamically change advertised UUID via SerialBLEInterface
Both platforms provide identical user experience for mode switching.
Compatibility
References
Bitchat Android AppMeshCore Companion Protocol: companion_protocol.mdMeshCore Packet Structure: packet_format.md
